Models:
Works with Teleflex Pump found on Late SX Models
Replaces:
API Marine
PT407NM-3
Arco Marine
6233
MES Motorcycle & Marine
T1084M
Remy Small Motor
RT05043
Volvo Penta
3861575
Voltage: 12V
Rotation: Reversible
Field Housing OD: 76.2 mm / 3.000 in
Overall Length: 150 mm / 5.906 in
Shaft OD: 8 mm / 0.315 in
Shaft Notes: 3.7 mm X 8 mm Drive Tang
Approximate Weight: 8 lbs / 1.36 kg
Notes:
2-Wire Connection
10-24 Thru Bolts
2.3″ Bolt Pattern
